High-friction, slip-resistant material has a special aluminum backing that conforms around corners and adheres to irregular surfaces. Applications: diamond grade safety plates, steps and ladder rungs. Heavy equipment and vehicles. Available in custom sizes and with custom adhesives. 3M™ Safety-Walk™ Slip Resistant Tapes and Treads Series 500 has been certified by the National Floor Safety Institute (NFSI) as providing “high-traction.” A wet static coefficient of friction (SCOF) of greater than 0.60 was chosen by NFSI as the criteria for “high traction” because according to NFSI, floor surfaces maintaining this level of slip resistance when wet have proven to reduce slip-and-fall claims by between 50% and 90%.ResourcesAIL
| Adhesives | Yes |
| Adhesive Type | PSA |
| Application | Irregular or Contoured Surface, Traction |
| Brand | Safety-Walk™ |
| Chemical Resistance | See Technical Data Sheet |
| Coefficient of Friction | See Technical Data Sheet |
| Color Family | Black |
| Fire Retardancy | Pass |
| Form Type | Roll, Tread |
| Maximum Service Temp | 175°F (79°C) |
| Minimum Application Temp | 40°F (4°C) |
| Minimum Application Temp. (Metric) | 4°C |
| National Stock Number | 8040015260624 |
| Overall Length (Imperial) | 24 in, 60 ft |
| Overall Length (Metric) | 18.3 m, 61 cm |
| Overall Thickness (Metric) | 0.76 mm, 0.9 mm |
| Overall Width (Imperial) | 12 in, 18 in, 2 in, 24 in, 4 in, 6 in |
| Overall Width (Metric) | 101.6 mm, 152.4 mm, 304.8 mm, 457 mm, 50.8 mm, 609.6 mm |
| Placement Area | Food Preparation, Industrial Equipment, Industrial Floors, Ramps/Catwalks/Platforms, Recreational/Sports Equipment, Stairs/Steps/Stairwells |
| Product Color | Black |
| Product Series | 500 – Conformable |
| Product Type | Anti-Slip Tapes, Conformable |
| Quantity | 1, 2, 50 |
| RoHS 2011/65/EU Compliant | Yes |
| Size | 18″ x 60′, 24″ x 60′, 4″ x 60′, 6″ x 60′, 6″ x24″ |
| Substrate Material | Aluminum Foil |
| Surface Material | Mineral |
| Surface Type | Irregular |
| TDS Required | Yes |
| Third Party Certification | ANSI/NFSI B101.1 and B101.3 |
| Traffic Type | Heavy, Light, Medium |
| Traffic Volume (Crossings per day) | Light Vehicle, Pedestrian |
| Tread Grade | Heavy Duty |
Details
- For irregular or contoured surfaces in light to heavy shoe-traffic areas
- Mineral-coated, high friction slip-resistant surface
- Aluminum backing conforms to corners, curves and irregular surfaces like diamond plating, riveted plates and ladder rungs
- Aggressive, high performance adhesive forms an excellent bond for a secure hold
- Applications: stairs, ladders, loading ramps, platforms, irregular surfaces like diamond plating or flat surfaces with rivets or screw heads
- Tapes and treads resist wrinkling, curling, tearing, shrinking, and lifting
- Custom shapes and sizes are also available
- NFSI High Traction Certification
Ideal for use on diamond grade safety plates, steps and other irregular surfaces. Mineral coated, slip-resistant with aluminum foil backing. Conforms to irregular surfaces and around edges.
