3M™ Safety-Walk™ White Printable Slip-Resistant Tapes and Treads in Pakistan

For Sales inquiry please call us at 03332890101

3M Printable Safety Walk

Printable tapes and treads are a cost-effective way to enhance the safety of traffic areas and display customized promotional or brand messages.

Marked safe from slips, trips and falls.

Nothing’s more important than the safety of your guests. And now you have a safety product that does double duty. 3M™ Safety-Walk™ Slip-Resistant General Purpose and Conformable White Tapes and Treads are certified as high traction by the National Floor Safety Institute (NFSI). And the white, printable surface can be 100% inked with your high- resolution, high-impact graphics, providing endless possibilities for your branding and safety messages.

Safe: Mineral-coated, slip-resistant material keeps even heavy-traffic areas safer.

Durable: Long-lasting adhesive.

Cost-effective: Lower material cost and less required labor.

Easy: No specialized training required for installation.

Printable: Heighten safety while displaying brand or promotional messages.

Product nameSizeUPC numberStock number
3M™ Safety-Walk™ Slip-Resistant General Purpose Tapes and Treads 688 White48 in x 150 ft006-38060-37232-675-0400-5766-5
3M™ Safety-Walk™ Slip-Resistant Conformable Tapes and Treads 588 White48 in x 150 ft006-38060-37231-975-0400-5765-7

3M™ Safety-Walk™ Slip-Resistant General Purpose Tapes and Treads 600 Series

For Sales inquiry please call us at 03332890101

Specifications

Adhesive TypePSA
Anti-slip MaterialMineral
Backing (Carrier) MaterialPoly Coated Paper, Polyester
BrandSafety-Walk™
Color FamilyBlack, Multi-color, Transparent, White, Yellow
Minimum Operating Temperature (Celsius)4 Degree Celsius
Minimum Operating Temperature (Fahrenheit)40 Degree Fahrenheit
Overall Length (Imperial)150 ft, 24, 24 in, 30 ft, 5.5 in, 60, 60 ft
Overall Length (Metric)0.6, 0.6 m, 139.7 mm, 18.288 m, 18.3 m, 45.72 m, 610 mm, 9 m, 9.14 m
Overall Width (Imperial)0.75 in, 1, 1 in, 12 in, 18 in, 2 in, 2.953 in, 24 in, 3 in, 36 in, 4 in, 47.244 in, 48, 48 in, 5.5 in, 5.984 in, 6, 6 in
Overall Width (Metric)101.6 mm, 1200 mm, 1219.2, 1219.2 mm, 139.7 mm, 152, 152 mm, 152.4 mm, 19.05 mm, 25.4, 25.4 mm, 304.8 mm, 457.2 mm, 50 mm, 50.8 mm, 609.6 mm, 76.2 mm, 760 mm, 914.4 mm
Product ColorBlack, Safety Yellow, Transparent, White, Yellow
Product Series600 – General Purpose
Quantity1, 10, 2, 4, 50
Size (Imperial)0.75 in x 24 in, 0.75 in x 60 ft, 1 in x 60 ft, 12 in x 60 ft, 18 in x 60 ft, 2 in x 30 ft, 2 in x 60 ft, 2.953 in x 60 ft, 24 in x 60 ft, 3 in x 30 ft, 3 in x 60 ft, 36 in x 60 ft, 4 in x 30 ft, 4 in x 60 ft, 47.244 in x 60 ft, 48 in x 150 ft, 48 in x 60, 48 in x 60 ft, 48 x 60, 48 x 60 ft, 5.5 in x 5.5 in, 5.984 in x 60 ft, 6 in x 24, 6 in x 24 in, 6 in x 30 ft, 6 in x 60 ft, 6 x 24, 6 x 24 in
Size (Metric)101.6 mm x 18.3 m, 101.6 mm x 9.14 m, 1200 mm x 18.3 m, 1219.2 mm x 18.3 m, 1219.2 mm x 45.72 m, 1219.2 x 18.3 m, 139.7 mm x 139.7 mm, 152 mm x 18.3 m, 152 x 0.6, 152 x 0.6 m, 152.4 mm x 0.6, 152.4 mm x 0.6 m, 152.4 mm x 18.3 m, 152.4 mm x 610 mm, 152.4 mm x 9 m, 19.05 mm x 18.3 m, 19.05 mm x 610 mm, 25.4 mm x 18.3 m, 304.8 mm x 18.3 m, 457.2 mm x 18.3 m, 50 mm x 18.3 m, 50.8 mm x 18.288 m, 50.8 mm x 18.3 m, 609.6 mm x 18.3 m, 76.2 mm x 18.3 m, 76.2 mm x 9.14 m, 760 mm x 18.3 m, 914.4 mm x 18.3 m
Specifications MetANSI/NFSI B101.1, ANSI/NFSI B101.3, U.S. MIL-PRF-24667C
TDS RequiredYes
Tread GradeHeavy Duty

Details

  • For light to heavy shoe traffic areas
  • Mineral-coated, high friction slip-resistant surface
  • Highly durable surface withstands the rigors of equipment traffic
  • Low-profile design helps reduce trip hazard
  • High performance pressure-sensitive adhesive for easy application
  • Applications: flat surfaces, steps, stairways, entrances, ramps, ladders, lawn equipment, snowmobiles, scooters, construction machinery and vehicles
  • Custom shapes and sizes are also available
  • NFSI High Traction Certification

This mineral coated, slip resistant material features a highly durable surface. Low profile design helps reduce trip hazards.

3M™ Safety-Walk™ Slip Resistant Tapes and Treads Series 600 has been certified by the National Floor Safety Institute (NFSI) as providing “high-traction.” A wet static coefficient of friction (SCOF) of greater than 0.60 was chosen by NFSI as the criteria for “high traction” because according to NFSI, floor surfaces maintaining this level of slip resistance when wet have proven to reduce slip-and-fall claims by between 50% and 90%.

Brochures

Bulletins

Data Sheets

Flyers

Safety Data Sheets

3M™ Safety-Walk™ Edging Compound for in Pakistan

3M™ Safety-Walk™ Edging Compound
3M™ Safety-Walk™ Edging Compound

Description

Details

  • Protects exposed edges of 3M™ Safety-Walk™ Slip-Resistant Materials from excessive moisture or liquids.

3M™ Safety-Walk Edging Compound is a liquid, solvent-based sealer that protects exposed edges of slip-resistant tapes and treads from excessive moisture or liquids.

Resources

Safety Data Sheets

How to choose a Linear Light for the commercial project Part – 1

The Perfect Commercial Led Linear Light

The linear light is not a simple product it is a light with a lot of customization involved it means that it as an art with lot of expertise required to make it. Now I will tell you what facts you should consider while choosing customized linear light.

Local Assembling or a Manufacturing unit: This is the first thing you should think before finalizing a light. This is not about unpacking a light, connecting power & attaching hanging kits! its about choosing a right company or a manufacturer which must be in your reach so you will be able to see the actual manufacturing process and the premises where your product will be manufactured. Think what if you are in US & you ordered your light from china & the light is made bigger or smaller than your required size; will send the light back to China? will you have that much time? & what is the guarantee that you are going to have a right light again. A local assembly unit or manufacturer near you is very important.

After Sales & Inventory: The light is comprised of several components i.e PCB (where the leds are placed, the drivers (which starts the light & convert 220 volts to 24v or 12v), Aluminum Profile, the pasting glue or a thermal double sided tape, reflectors, diffusers, jointers, cables, end caps & the hanging kits. So you have to keep this thing in your mind whether your supplier will give you proper assistance in case of multi components failure. And what is the lead time if you are facing a component relating issue.

Electrical Consultancy : If you are working on a large scale project and you need a perfect product so you should consult a right Electrical Consultant. It will serve you three basic purposes; one the consultant will verify the specifications & light output, secondly they will validate the status of the manufacturer incase of new or an experienced lighting company. Two Electrical Consultant plays a vital roll in choosing and suggesting a right product, at the time of installations & after project completion. Three what to install & how install.

Product Specifications: There are products which needs to be specified and get approval by the consultants. For example a company is selling a linear light at an standard length of 1.2 meters which is taking 40watts and generating output of 3600 lumens with .9 power factor. These are the specifications which are provided the manufacturer but who is going to verify whether the specifications are correct is electrical consultant. Now its time to measure the flexibility or range of customization as the standard size is 1.2 meter which is very close to 4 feet but but you need light in multiple lengths like 5 feet, 6 feet, 8 feet, 12 feet or even 15 to 50 feets. Now four major components play a vital roll in deciding whether the light is customizable enough or not. One is the “PCB” (on which the lighting chips are placed) cuttable or can be joint at multiple lengths & what is the process of joining the PCB? the answer is that the PCB can be cut at shorter length of every 100mm and the total length of a single PCB is 1200mm. It means that the PCB is customizable. Two is the “Driver” of the PCB supports upto how much length? in our case the PCB is supporting 1200mm at maximum wattage of 40w what if the the length is 600mm or 2400mm? so we have to use a driver of 20w for 600mm and 80w driver for 2400mm. Three is the “Difuser”. The difuser is used to difuse the glare of the light produced by the led chips so you have to look whether diffuser diffusing the glare & producing enough light (make sure that leds are not visible) if leds are still visible it means the diffuser is not performing enough to bypass smooth lighting. The maximum length of the diffuser is another important factor for example you need the maximum size of 16 feet but the manufacturer is providing the maximum length of 8 feet so it is obvious that two lengths of 8 feet diffuser will be used to make a sixteen feet light. A sharp line can seen between the two difusers but this thing is normal. Four the “Aluminum Profile”; this is the most important part on which a light & all components based.

San’an among the top Led Chip maker in China – Part 2

San’an Optoelectronics Co., Ltd

Lets continue to the lighting series chips of San’an. (if you new to this post you need review the previous post to follow the sequence)

Specifications & Classification of San’an Led Chips.

2. Lighting

HV Chip by San'an
VoltageChip series Suitable PKG Application PerformanceAdvantage
9V
18
2835/3030illumination[email protected] 100% test sorting,high brightness,long operating life
9V
262835/3030illumination[email protected] 100% test sorting,high brightness,long operating life
9V
282835/3030illumination[email protected] 100% test sorting,high brightness,long operating life
9V
342835/3030illumination[email protected] 2D 100% test sorting,high brightness,long operating life
9V
39
2835/3030illumination[email protected] 2D 100% test sorting,high brightness,long operating life
9V
352835/3030illumination~145lm/[email protected] 2D 100% test sorting,high brightness,long operating life
18V 162835/3030illumination[email protected] 30mA 100% test sorting,high brightness,long operating life
18V 232835/3030illumination[email protected] 30mA 100% test sorting,high brightness,long operating life
18V 242835/3030illumination[email protected] 30mA 100% test sorting,high brightness,long operating life
18V 272835/3030illumination[email protected] 30mA 100% test sorting,high brightness,long operating life
18V 302835/3030illumination[email protected] 30mA 100% test sorting,high brightness,long operating life
18V 372835/3030illumination[email protected] 60mA 100% test sorting,high brightness,long operating life

the post is continue to Next Page

San’an among the top Led Chip maker in China

San’an Optoelectronics Co., Ltd

Those who are in the feild of led lighting know this huge name of San’an. Here in 2022; the 22 year old company crceating difference by ist R&D in four core areas i.e Led Chip, Filter, Power Electronics, Microwave Integrated Circuit & Optical Communication.

Lets see the their Led Production Spectrum by veiwing their GaN Products:

  • Display
  • Lighting
  • Tv Backlight
  • 020 Backlight
  • Digital
  • FC
  • VTF
  • UV
  • Mini
  • Automative

1. DISPLAY

Indoor display by San'an
Chip series Suitable PKG Application SpecAdvantage
06A2121/1515/1212P2-P40.5V/8、10、12nm binning 100% test sorting, High refresh frequency,
08F1010/2121P1.2-P40.3V/2nm binning 100% test sorting, High refresh frequency,
08H1010/2121P0.9-P40.3V/2nm binning 100% test sorting, High refresh frequency,

Outdoor display by San'an
Chip series Suitable PKG Application SpecAdvantage
08DG1921/2525/2727P4-P100.5V/10nm binning100% test sorting, High refresh frequency,
long operating life
10A2727/2525/3535P4-P10 0.3V/2.5nm binning 100% test sorting, High refresh frequency,
long operating life
13C 2727/3535 P4-P160.3V/2.5nm binning 100% test sorting, High refresh frequency,
long operating life
16A346/3535P4-P10 0.3V/2.5nm binning 100% test sorting, High refresh frequency,
long operating life

2. Lighting

0.2W Chip by San'an
Chip series Suitable PKG Application PerformanceAdvantage
17
2835/3030Lighting [email protected] 100% test sorting,long operating life
Low voltage, high brightness
182835/3030Lighting [email protected] 100% test sorting,long operating life
Low voltage, high brightness
272835/3030 Lighting [email protected] 100% test sorting,long operating life
Low voltage, high brightness
302835/3030Lighting [email protected] 100% test sorting,long operating life
Low voltage, high brightness

0.5W Chip by San'an
Chip series Suitable PKG Application PerformanceAdvantage
30
2835/3030Lighting [email protected] 100% test sorting,long operating life
Low voltage, high brightness
322835/3030Lighting [email protected] 100% test sorting,long operating life
Low voltage, high brightness
342835/3030 Lighting 210lm/[email protected] 100% test sorting,long operating life
Low voltage, high brightness
352835/3030Lighting 220lm/[email protected] 100% test sorting,long operating life
Low voltage, high brightness
402835/3030Lighting 222lm/[email protected] 100% test sorting,long operating life
Low voltage, high brightness
422835/3030Lighting 223lm/[email protected] 100% test sorting,long operating life
Low voltage, high brightness
462835/3030Lighting 225lm/[email protected] 100% test sorting,long operating life
Low voltage, high brightness

1W Chip by San'an
Chip series Suitable PKG Application PerformanceAdvantage
45
3535Lighting >[email protected] 100% test sorting,long operating life
Low voltage, high brightness

the post is continue to Next Page
