3M Adhesive Transfer Tape 9447

3M Adhesive Transfer Tape 9447: Are you in need of a high-performance adhesive tape that offers exceptional flagging resistance and adhesion to a wide range of substrates? Look no further than 3M™ Adhesive Transfer Tape 9447. With its clear, 1 mil construction, this tape provides reliable bonding capabilities, making it a go-to choice for many industries. In this article, we will explore the features and benefits of 3M™ Adhesive Transfer Tape 9447, along with its recommended applications and properties.

Introduction

3M™ Adhesive Transfer Tape 9447 is a specially designed tape that offers excellent adhesion and flagging resistance. It features a high tenacity acrylic adhesive, which ensures strong bonding to various substrates. The tape is mounted on a 55 lb. densified kraft paper liner, making it suitable for rotary die-cutting applications.

Features and Highlights

The key features and highlights of 3M™ Adhesive Transfer Tape 9447 are as follows:

High Tenacity Acrylic Adhesive

The tape utilizes a high tenacity acrylic adhesive that provides exceptional flagging resistance and adhesion. This adhesive is known for its durability and reliability, making it suitable for a wide range of applications.

Densified Kraft Paper Liner

With a 55 lb. densified kraft paper liner, this tape offers an ideal surface for rotary die-cutting applications. The liner ensures consistent performance and ease of use during the application process.

Heat Resistance

3M™ Adhesive Transfer Tape 9447 exhibits heat resistance up to 150°F / 65°C, with short-term resistance up to 250°F / 121°C. This allows the tape to maintain its bonding capabilities even at high temperatures, making it suitable for applications in demanding environments.

Excellent Chemical Resistance

The tape is designed to withstand various chemicals, ensuring reliable performance during laminate processes. Its excellent chemical resistance allows it to endure harsh conditions and maintain its integrity.

Thin Bond Line

The adhesive transfer tape creates a thin bond line, which is advantageous for applications where a minimal bond thickness is desired. This feature ensures efficient and effective bonding without adding unnecessary bulk.

Applications and Versatility

3M™ Adhesive Transfer Tape 9447 finds application in a variety of industries and offers versatile uses. Some of the recommended applications include:

Protected Graphics Printing on Polyester Films

The tape is specifically designed for use with 3M™ Label Component Systems for graphics printing on polyester films. It provides a reliable adhesive solution for producing high-quality graphics with excellent adhesion and durability.

Custom Tamper-Inducing Labels

3M™ Adhesive Transfer Tape 9447 is commonly used in the creation of custom tamper-inducing labels. The tape’s strong adhesive properties, along with its heat resistance and chemical resistance, make it an ideal choice for applications that require secure and tamper-evident seals.

General Purpose Bonding

Due to its excellent flagging resistance and adhesion properties, 3M™ Adhesive Transfer Tape 9447 is suitable for general purpose bonding applications. It can be used to bond various substrates, offering a reliable solution for different industrial and commercial needs.

Understanding Adhesive Transfer Tapes

Adhesive transfer tapes, such as 3M™ Adhesive Transfer Tape 9447, are rolls of pressure-sensitive adhesive that are pre-applied to a special release liner. These tapes provide a convenient and efficient way to bond surfaces together. To apply the tape, simply press it, adhesive side down, onto the desired surface and peel off the liner. Adhesive transfer tapes are available in various adhesive properties and liners to meet specific application requirements.

Adhesive transfer tapes offer a wide range of uses across different industries. They are commonly used for nameplate attachment to both high and low surface energy plastics, appliance graphic overlays that are exposed to high temperatures, foam gasketing, web splicing, signs, posters, banners, point-of-purchase displays, and more. Their versatility and reliability make them a preferred choice for many bonding applications.

3M™ Adhesive Transfer Tape 9447: A Reliable Choice

3M Adhesive Transfer Tape 9447 is specifically designed to meet the demanding needs of various applications. Its high tenacity acrylic adhesive provides excellent flagging resistance and adhesion to a variety of substrates. The tape’s 55 lb. densified kraft paper liner ensures easy handling and is suitable for rotary die-cutting applications.

This adhesive transfer tape exhibits impressive heat resistance, withstanding temperatures up to 150°F / 65°C for extended periods and up to 250°F / 121°C for short-term applications. This feature allows the tape to maintain its bonding capabilities even in high-temperature environments, making it suitable for use in automotive hoods and outdoor applications.

Additionally, 3M™ Adhesive Transfer Tape 9447 offers excellent chemical resistance, enabling it to perform reliably during laminate processes. Its thin application of adhesive creates a thin bond line, which is advantageous for applications where a minimal bond thickness is desired.

Typical properties

Details

Adhesive TypeAcrylic
Brands3M™
IndustriesPrint, Converter Solutions, General Industrial
Maximum Operating Temperature (Celsius)121 ℃
Maximum Operating Temperature (Fahrenheit)250 ℉
Minimum Operating Temperature (Fahrenheit)-40 ℉
Primary Liner55# Densified Kraft Paper
Primary Liner ColorWhite
Primary Liner Thickness (Imperial)3.2 mil
Primary Liner Thickness (Metric)0.08 mm
Total Tape Thickness without Liner (Imperial)1 mil
Total Tape Thickness without Liner (Metric)0.025 mm

3M Adhesive Transfer Tape 9775WL

3M Adhesive Transfer Tape 9775WL: Are you in search of a reliable adhesive tape that offers exceptional bonding performance for foams, plastics, fabrics, and more? Look no further than 3M™ Adhesive Transfer Tape 9775WL. With its high bond strength, durability, and resistance to humidity, solvents, chemicals, and UV rays, this adhesive tape is designed to meet your bonding needs. In this article, we’ll explore the features, applications, and benefits of 3M™ Adhesive Transfer Tape 9775WL.

Introduction

When it comes to bonding materials such as foams, plastics, and fabrics, having a reliable adhesive tape is crucial. 3M™ Adhesive Transfer Tape 9775WL is designed to provide exceptional adhesion and durability in a wide range of applications. This adhesive tape features 5.0 mils (.13 mm) of adhesive on a 7.0 mils (.19 mm), 96 lb. white polycoated kraft liner. Its high tack acrylic adhesive, known as 3M™ Adhesive 300MP, ensures a strong initial bond that reaches full adhesion within 48 – 72 hours.

Key Features of 3M™ Adhesive Transfer Tape 9775WL

  • High Bond Strength: The adhesive used in 3M™ Adhesive Transfer Tape 9775WL delivers a high bond strength, making it ideal for bonding foams, plastics, fabrics, wood, and more.
  • Durability: This adhesive tape offers exceptional resistance to humidity, solvents, chemicals, and UV rays, ensuring long-lasting and durable bonds.
  • Temperature Resistance: 3M™ Adhesive Transfer Tape 9775WL performs well at temperatures up to 250ºF/121ºC, providing reliable bonding even in high-temperature environments.

Applications of 3M™ Adhesive Transfer Tape 9775WL

  1. Foam Gaskets and General Foam Bonding: Whether you need to create foam gaskets or bond different foam materials together, 3M™ Adhesive Transfer Tape 9775WL provides a reliable solution.
  2. Bonding of Textured and Rough Surfaces: With its ability to flow into crevices and voids, this adhesive tape is perfect for bonding textured and rough surfaces securely.
  3. Fabric and Textile Bonding: From laminating floorcoverings to joining fabric and textile materials, 3M™ Adhesive Transfer Tape 9775WL offers strong adhesion and excellent compatibility with various fabrics.
  4. Wood and Plastic Bonding: If you require a dependable adhesive for bonding wood and plastic substrates, this transfer tape is an ideal choice.

Easy Application and Versatility

3M™ Adhesive Transfer Tape 9775WL is designed for ease of use and versatility. The adhesive easily flows into crevices and voids without the need for additional heat or excessive pressure. The tape’s heavy polycoated kraft paper liner makes it suitable for die cutting and converting processes, providing flexibility in different applications. 3M™ Adhesive Transfer Tape 9775WL is designed to offer easy application and versatility. The adhesive on the tape effortlessly flows into crevices and voids without requiring additional heat or excessive pressure. This feature ensures a hassle-free bonding process, saving you time and effort.

The tape’s heavy polycoated kraft paper liner enhances its usability. It enables the tape to be easily cut and converted into various shapes and sizes, making it suitable for a wide range of applications. Whether you need precise shapes for intricate projects or larger dimensions for broader surfaces, 3M™ Adhesive Transfer Tape 9775WL can be tailored to meet your specific requirements.

Its flexibility and adaptability make it an excellent choice for industries such as packaging, automotive, electronics, construction, and more. You can confidently use this adhesive tape for tasks like foam gaskets, fabric bonding, rough surface adhesion, and wood and plastic bonding.

Detailed Properties for Enhanced Understanding

To provide a comprehensive overview, let’s examine the typical properties of the 3M™ Adhesive Transfer Tape 9775WL:

  • Adhesive Type: Acrylic
  • Brands: 3M™
  • Industries: Construction, General Industrial, Electronics, Specialty Vehicle, Transportation, Appliance, Automotive, Converter Solutions
  • Maximum Operating Temperature: 250ºF (121ºC)
  • Minimum Operating Temperature: -40ºF (-40ºC)
  • Primary Liner: 96# Polycoated Kraft Paper
  • Primary Liner Color: White
  • Primary Liner Thickness (Imperial): 7 mil
  • Primary Liner Thickness (Metric): 0.18 mm
  • Shelf Life: 18 Months
  • Total Tape Thickness without Liner (Imperial): 5 mil
  • Total Tape Thickness without Liner (Metric): 0.127 mm
  • Units per Case: 1.0 Roll
  • Overall Length (Imperial): 10 yd
  • Overall Length (Metric): 9.14 m, 164.59 m

These properties highlight the specific characteristics of the 3M™ Adhesive Transfer Tape 9775WL, enabling users to make informed decisions regarding its suitability for their applications.

Extended Liner 466XL: 3M Adhesive Transfer Tape

Extended Liner 466XL: When it comes to bonding a variety of materials with precision and ease, 3M™ Adhesive Transfer Tape Extended Liner 466XL takes the spotlight. This translucent tape, measuring 1/2 inch by 60 yards, is a reliable solution for numerous applications. With its pressure-sensitive adhesive and user-friendly features, it provides convenience, efficiency, and optimal results. In this article, we will explore the key highlights and benefits of 3M™ Adhesive Transfer Tape Extended Liner 466XL.

1. Introduction: The Power of Adhesive Transfer Tape

Adhesive transfer tapes are designed to simplify bonding processes by offering a layer of pressure-sensitive adhesive without any backing material. They provide a clean and efficient way to join different materials securely. Among these adhesive transfer tapes, 3M™ Adhesive Transfer Tape Extended Liner 466XL stands out for its remarkable performance and convenience.

2. Easy Liner Starting and Removal for Smooth Operations

The Extended Liner feature of 3M™ Adhesive Transfer Tape 466XL offers a significant advantage. The liner extends beyond the width of the adhesive, enabling easy starting and removal. This makes the application process smoother, eliminating potential frustrations and saving valuable time. Additionally, the tape provides a dry edge and finger lift edge on each side, ensuring effortless liner removal.

3. Recommended Applications: Versatility at Its Best

The versatility of 3M™ Adhesive Transfer Tape Extended Liner 466XL makes it suitable for various applications. Some common uses include:

  • Cardboard shipping boxes
  • Overnight mailer envelopes
  • Pharmaceutical outserts
  • Point of purchase displays and advertising
  • Core starting
  • Business forms
  • Paper-to-paper applications

These are just a few examples of the many possibilities this adhesive transfer tape offers. Its reliable bonding properties and easy liner removal make it an ideal choice across industries.

4. Reliable Sealing on a Variety of Substrates

The adhesive solutions provided by 3M™ Adhesive Transfer Tape Extended Liner 466XL offer dependable sealing on a wide range of substrates. Whether you’re working with coated or uncoated papers, films, plastics, foams, or metals, this tape delivers exceptional adhesion performance.

5. Adhesive Options: Choosing the Right Solution

3M™ Adhesive Transfer Tape Extended Liner 466XL is available with different adhesive options to suit specific requirements. Two notable adhesive types are:

  • 3M™ Adhesive 400 Acrylic: Known for its high initial adhesion and good shear holding power, this adhesive is perfect for bonding paper materials.
  • 3M™ Adhesive 340 Acrylic: This adhesive offers very high tack and is commonly used for pharmaceutical outsert attachment.

Depending on the application, you can choose the adhesive option that best fits your needs.

6. Understanding Adhesive Transfer Tapes

Adhesive transfer tapes, such as the 3M™ Adhesive Transfer Tape Extended Liner 466XL, play a crucial role in various industries. Their adhesive-only composition, combined with easy liner starting and removal, makes them highly versatile and efficient. These tapes provide a reliable solution for bonding materials without the need for traditional backing materials.

7. Bringing Better Ideas to the Surface through Science and Innovation

At 3M’s Industrial Adhesives and Tapes Division, their commitment to science and innovation is evident. They continuously strive to develop adhesive solutions that improve design and manufacturing processes worldwide. By incorporating advanced technologies, 3M helps customers deliver competitive products more efficiently and quickly to the market.

8. Typical Properties of 3M™ Adhesive Transfer Tape Extended Liner 466XL

To better understand the capabilities of 3M™ Adhesive Transfer Tape Extended Liner 466XL, let’s explore its typical properties:

  • Adhesive Type: High Tack Acrylic Adhesive 340
  • Brand: 3M™
  • Industries: Medical, Retail, Packaging, Paper, Print, General Industrial
  • Maximum Operating Temperature: 180 ℉
  • Minimum Operating Temperature: -40 ℉
  • Primary Liner: 62# Densified Kraft Paper
  • Primary Liner Color: White
  • Primary Liner Thickness (Imperial): 4 mil
  • Primary Liner Thickness (Metric): 0.1 mm
  • Total Tape Thickness without Liner (Imperial): 2 mil
  • Total Tape Thickness without Liner (Metric): 0.05 mm
  • Units per Case: 72.0 Rolls
  • Overall Length (Imperial): 500 yd
  • Overall Width (Imperial): 0.5 in
  • Overall Width (Metric): 12.7 mm

These properties highlight the tape’s durability, temperature resistance, and overall performance, making it a reliable choice for various applications.

3M Adhesive Transfer Tape 468MP: Great Strength & Versatility

3M Adhesive Transfer Tape 468MP: In the world of industrial adhesives, 3M™ has long been a trusted name, known for its innovative solutions and superior performance. One such product that stands out is the 3M™ Adhesive Transfer Tape 468MP. With its exceptional peel and shear strength, versatility, and reliability, this adhesive transfer tape is a go-to choice for various bonding applications. In this article, we will explore the features, benefits, and recommended uses of the 3M Adhesive Transfer Tape 468MP, showcasing why it is an industry standard for graphic attachment and general industrial joining applications.

Introduction

The 3M™ Adhesive Transfer Tape 468MP is designed to deliver exceptional bonding performance for various materials, including metals and high surface energy (HSE) plastics. With its unique combination of peel and shear strength, it offers a reliable and durable bond that withstands demanding applications. Whether you’re working on splicing, laminating, or graphic attachment, this adhesive transfer tape is a valuable tool in your arsenal.

Delivers exceptional peel and shear strength for metals and HSE plastics

One of the standout features of the 3M Adhesive Transfer Tape 468MP is its exceptional peel and shear strength. The 5.2 mil adhesive provides a robust bond that holds firm even under stress. Whether you’re bonding metal nameplates, rating plates, or graphic overlays to textured surfaces, this tape ensures a secure attachment that lasts.

58# polycoated kraft paper (PCK) liner for high strength bond

To complement its adhesive properties, the 3M™ Adhesive Transfer Tape 468MP features a 58# polycoated kraft paper (PCK) liner. This liner offers a high strength bond, making it ideal for splicing and laminating applications. The polycoated surface enhances the tape’s overall performance, allowing for efficient rotary processing of graphic and die cut parts.

Thicker adhesives for improved wet-out and adhesion on textured surfaces

The 3M™ Adhesive Transfer Tape 468MP incorporates thicker adhesives, which contribute to improved wet-out and adhesion on textured surfaces. Even when faced with slight textures or irregularities, this tape ensures optimal adhesion. It eliminates the concern of compromised bonding due to surface variations, providing a reliable solution for a wide range of applications.

Provides high resistance to solvents and humidity

When it comes to reliability, the 3M™ Adhesive Transfer Tape 468MP doesn’t disappoint. It provides exceptional resistance to solvents and humidity, ensuring the longevity of the bond. This feature makes it an excellent choice for applications where exposure to harsh conditions is expected.

200MP acrylic adhesive: The industry standard for graphic attachment

The 3M™ Adhesive Transfer Tape 468MP utilizes the renowned 200MP acrylic adhesive, which is widely recognized as the industry standard for graphic attachment and general industrial joining applications. With its proven track record and superior performance, this adhesive delivers consistent results and surpasses expectations.

Outstanding adhesion on metals and HSE plastics

Thanks to its formulation and design, the 3M™ Adhesive Transfer Tape 468MP exhibits outstanding adhesion on both metals and high surface energy (HSE) plastics. This versatility allows it to be used in various industries and applications where bonding strength and durability are crucial.

Recommended applications

The 3M™ Adhesive Transfer Tape 468MP finds its application in a wide range of industries and bonding scenarios. Here are some of its recommended uses:

  1. Bonding metal nameplates and rating plates: This tape ensures a secure and long-lasting bond between metal nameplates and various surfaces.
  2. Long-term bonding of graphic nameplates and overlays: Specifically designed for textured metals and high surface energy plastics, the tape provides reliable adhesion for graphic nameplates and overlays.
  3. High-speed processing of parts: Whether it’s medical components, durable labels, or flexible circuits, the 3M™ Adhesive Transfer Tape 468MP offers efficient bonding solutions.
  4. Bonding graphic overlays for membrane switches: The tape is an excellent choice for bonding graphic overlays to membrane switches, ensuring a durable and functional interface.
  5. Bonding complete switches to equipment surfaces: It provides a reliable bond between switches and equipment surfaces, ensuring seamless integration.

Featuring 3M™ High Performance Acrylic Adhesive 200MP

More than 30 years ago, 3M™ High Performance Acrylic Adhesive 200MP set the standard for bonding metal and high surface energy plastics. Today, this adhesive continues to deliver exceptional performance with its excellent peel and shear strength. It offers resistance to moisture, solvents, and high temperatures up to 400°F / 204°C, making it suitable for a wide range of demanding applications.

Understanding adhesive transfer tapes

Adhesive transfer tapes are rolls of pressure-sensitive adhesive pre-applied to a special release liner. When applying the tape, simply press the adhesive side onto the desired surface and peel off the liner. Adhesive transfer tapes provide convenience, efficiency, and reliable bonding solutions for applications such as nameplate attachment, graphic overlays, foam gasketing, signs, and more.

Bringing better ideas to the surface through science

In the 3M Industrial Adhesives and Tapes Division, science is at the heart of developing innovative adhesive solutions. By applying the principles of adhesion, 3M delivers products that enhance design and manufacturing processes worldwide. The goal is to empower customers to bring competitive and high-quality products to the market efficiently.

Typical properties of 3M™ Adhesive Transfer Tape 468MP

The 3M™ Adhesive Transfer Tape 468MP exhibits various typical properties that make it a versatile and reliable adhesive solution. Here are the key details:

Adhesive Type: The adhesive used in this tape is an acrylic-based formulation known as High-Performance Acrylic Adhesive 200MP. It offers excellent bonding performance and durability.

Application: The tape is suitable for various applications, including large surface lamination assembly, mounting and trim attachment, and gasket assembly. Its versatility allows it to be used in multiple industries.

Automotive OEM Specification: The 3M Adhesive Transfer Tape 468MP complies with the specifications of several automotive Original Equipment Manufacturers (OEMs). These specifications include FCA MS-CC240, Ford WSS-M11P62, GM 9985274, GMW 14892, Ford WSS-M99P48-A3, and FCA 9.55368. Meeting these specifications ensures that the tape meets the rigorous requirements of the automotive industry.

Brands: The adhesive tape is manufactured by 3M™, a renowned brand known for its quality and innovation in adhesive solutions.

Indoor/Outdoor Use: The 3M™ Adhesive Transfer Tape 468MP is suitable for both indoor and outdoor applications, providing reliable performance in various environmental conditions.

Industries: This adhesive tape finds applications in a wide range of industries, including woodworking, appliance manufacturing, automotive, point of purchase, converter solutions, medical, maintenance, repair, and operations (MRO), signage, specialty vehicles, aerospace, general industrial, printing, electronics, metalworking, military and government, transportation, retail, and packaging.

Operating Temperature: The tape can withstand temperatures ranging from -40°C to 204°C (-40°F to 400°F), allowing it to maintain its adhesive properties in extreme temperature conditions.

Primary Liner: The adhesive is backed by a 58# polycoated kraft paper (PCK) liner, which provides strength and stability during application. The liner is tan in color.

Shelf Life: The tape has a shelf life of either 18 months or 24 months, depending on the specific product.

Total Tape Thickness: The adhesive tape has a total thickness of 5.2 mil (0.132 mm) without the liner.

Units per Case: The tape is available in various roll quantities per case, ranging from 1.0 roll to 72.0 rolls, providing options for different usage needs.

Dimensions and Classifications: The tape comes in different overall lengths and widths, both in imperial and metric measurements, allowing flexibility for different application requirements.

Adhesive TypeAcrylic, High Performance Acrylic Adhesive 200MP
ApplicationLarge Surface Lamination Assembly, Mounting & Trim Attachment, Gasket Assembly
Automotive OEM SpecificationFCA MS-CC240, Ford WSS-M11P62, GM 9985274, GMW 14892, Ford WSS-M99P48-A3, FCA 9.55368
Brands3M™
Indoor/OutdoorIndoor/Outdoor
IndustriesWoodworking, Appliance, Automotive, Point of Purchase, Converter Solutions, Medical, MRO, Signage, Specialty Vehicle, Aerospace, General Industrial, Print, Electronics, Metalworking, Military & Government, Transportation, Military, Retail, Packaging
Maximum Operating Temperature (Celsius)204 ℃
Maximum Operating Temperature (Fahrenheit)400 ℉
Minimum Operating Temperature (Celsius)-40 ℃
Minimum Operating Temperature (Fahrenheit)-40 ℉
Primary Liner58# Polycoated Kraft Paper
Primary Liner ColorTan
Primary Liner Thickness (Imperial)4.2 mil, 4.2 none
Primary Liner Thickness (Metric)0.11 mm
Shelf Life18 Month, 24 Month
Total Tape Thickness without Liner (Imperial)5.2 mil
Total Tape Thickness without Liner (Metric)0.132 mm, 0.13 mm
Units per Case1.0 Roll,8.0 Roll,24.0 Roll,4.0 Roll,36.0 Roll,48.0 Roll,12.0 Roll,72.0 Roll

Dimensions and Classifications

Overall Length (Imperial)180 yd, 60 yd, 360 yd, 120 yd
Overall Length (Metric)164.59 m, 54.86 m, 165.59 m, 329.18 m, 109.72 m, 109.73 m
Overall Width (Imperial)9 in, 0.75 in, 3 in, 60 in, 1 in, 16 in, 18 in, 13.5 in, 23 in, 27 in, 20 in, 6 in, 12.5 in, 48 in, 0.5 in, 9.6 in, 54 in, 24 in, 10 in, 13 in, 12 in, 2 in, 23.75 in, 11.75 in, 59 in, 11 in
Overall Width (Metric)228.6 mm, 19.05 mm, 76.2 mm, 1,524 mm, 25.4 mm, 406.4 mm, 457.2 mm, 342.9 mm, 584.2 mm, 685.8 mm, 508 mm, 152.4 mm, 317.5 mm, 1,219.2 mm, 12.7 mm, 243.84 mm, 1,371.6 mm, 609.6 mm, 254 mm, 330.2 mm, 304.8 mm, 50.8 mm, 603.25 mm, 298.45 mm, 1,498.6 mm, 279.4 mm

3M Extended Liner 465XL: Adhesive Transfer Tape

3M Extended Liner 465XL: When it comes to adhesive tapes, reliability and ease of use are essential. Whether you’re working on a project that requires bonding paper materials or other surfaces, 3M™ Adhesive Transfer Tape Extended Liner 465XL is the go-to choice. With its unique features and exceptional performance, this translucent adhesive tape provides a strong bond while ensuring easy liner removal. In this article, we’ll explore the product description, features, and various applications of 3M™ Adhesive Transfer Tape Extended Liner 465XL.

Introduction

When it comes to adhesive solutions, 3M™ is a trusted name in the industry. With their commitment to innovation and quality, they have developed the 3M™ Adhesive Transfer Tape Extended Liner 465XL. This translucent tape is designed to provide a reliable bond while offering ease of use and efficient liner removal. Whether you’re working on posters, point-of-purchase displays, business forms, or pharmaceutical outsert attachment, this adhesive transfer tape is the ideal choice.

Product Description

The 3M™ Adhesive Transfer Tape Extended Liner 465XL features a liner that extends beyond the width of the adhesive, making it easy to start and remove the liner. The tape is translucent, allowing for discreet bonding without compromising on performance. The liner is printed with the message, “Remove to Expose Adhesive,” ensuring that users are aware of the proper usage.

Product Features

  • Extended Liner: The extended liner of the tape provides a dry edge on each side, facilitating easy liner removal.
  • Versatile Application: While ideal for adhesion to paper materials, the 3M™ Adhesive Transfer Tape Extended Liner 465XL also works well on various other surfaces.
  • Pressure-Sensitive Edges: This tape is perfect for creating pressure-sensitive edges for posters and point-of-purchase sales advertising, as well as permanent mounting of novelty items, note pads, literature, posters, and labels.
  • Business Forms: The pressure-sensitive edging capability of this tape makes it suitable for use on business forms, ensuring secure adhesion.
  • Pharmaceutical Outsert Attachment: With a thickness of 0.002 inches, the 3M™ Adhesive Transfer Tape 465XL is ideal for pharmaceutical outsert attachment, providing the necessary adhesive mass for secure bonding.

Applications of 3M™ Adhesive Transfer Tape Extended Liner 465XL

The 3M Extended Liner 465XL “Adhesive Transfer Tape” finds its application in various industries and projects, including:

  1. Posters and Point-of-Purchase Displays: The strong bond and pressure-sensitive edges of the 3M™ Adhesive Transfer Tape Extended Liner 465XL make it ideal for creating durable and visually appealing posters and point-of-purchase displays. It ensures that the graphics remain securely attached, even in high-traffic areas.
  2. Business Forms: This adhesive tape is well-suited for securing business forms, such as invoices, receipts, and order forms. Its reliable adhesion ensures that the forms stay in place during handling and transportation, preventing accidental detachment or loss of important information.
  3. Pharmaceutical Outsert Attachment: The 3M™ Adhesive Transfer Tape Extended Liner 465XL is commonly used for attaching pharmaceutical outserts, which are informative inserts included in medication packaging. The tape provides a strong and secure bond, ensuring that the outsert remains attached throughout the life cycle of the product.
  4. Labeling and Packaging: With its excellent adhesion properties, the 3M™ Adhesive Transfer Tape Extended Liner 465XL is ideal for labeling and packaging applications. It securely attaches labels to various surfaces, including cardboard, plastic, and metal, offering reliable identification and branding for products.
  5. Automotive Interior Trim: The 3M™ Adhesive Transfer Tape Extended Liner 465XL is suitable for bonding automotive interior trim components, such as dashboard panels, door trims, and console covers. It provides a strong and durable bond that withstands temperature variations and vibration, ensuring long-lasting performance.
  6. General Assembly: In various assembly processes, the 3M Extended Liner 465XL “Adhesive Transfer Tape” can be used for bonding lightweight materials, such as foam, fabric, and plastics. It eliminates the need for traditional liquid adhesives, simplifying the assembly process and reducing the risk of mess and waste.

Technical Information

  • Adhesive Type: Acrylic
  • Liner Type: Extended Liner
  • Color: Translucent
  • Thickness: 2 mil (0.002 inches)
  • Adhesive Mass: 1.5 mil (0.0015 inches)
  • Temperature Resistance: Up to 300°F (149°C)
  • Release Liner Thickness: 3.2 mil (0.0032 inches)
  • Tensile Strength: 25 lb/in (43.7 N/10 mm)
  • Elongation: 550%
  • Core Size: 3 inches

Available Sizes

The 3M™ Adhesive Transfer Tape Extended Liner 465XL is available in various sizes to suit different application needs:

  1. 1 in x 600 yd, 2 mil (9 per case)
  2. 1/2 in x 600 yd, 2 mil (18 per case)
  3. 1/2 in x 60 yd, 2 mil, 72 per case
  4. 1 in x 600 yd, 2 mil, 9 per case

Handling/Application Information

When using the 3M™ Adhesive Transfer Tape Extended Liner 465XL, follow these guidelines for proper handling and application:

  1. Ensure that the surfaces to be bonded are clean, dry, and free from oil, dust, and other contaminants.
  2. Apply firm and even pressure to ensure proper adhesive contact.
  3. Use a roller or squeegee to remove air bubbles and ensure a smooth bond.
  4. For best results, apply the tape at room temperature (70°F to 100°F or 21°C to 38°C).
  5. If necessary, the tape can be easily cut into specific shapes and sizes using a sharp blade or scissors.
  6. The extended liner design provides ease of handling and helps prevent the adhesive from sticking to unintended surfaces during application.
  7. Store the tape in a cool, dry place, away from direct sunlight and extreme temperatures.

Safety Precautions

When working with the 3M™ Adhesive Transfer Tape Extended Liner 465XL, it is important to observe the following safety precautions:

  1. Use in a well-ventilated area to avoid inhaling fumes or vapors.
  2. Avoid contact with skin and eyes. In case of contact, wash thoroughly with water and seek medical attention if irritation persists.
  3. Keep the tape away from open flames and sources of ignition, as it is flammable.
  4. Read and follow the instructions and warnings provided by 3M for safe handling and usage.

3M Adhesive Transfer Tape 9380: Aerospace Application

3M Adhesive Transfer Tape 9380: If you’re in the aerospace industry and looking for a reliable adhesive solution that offers excellent resistance to jet fuel, hydraulic fluid, solvents, humidity, moisture, and heat, then look no further than 3M™ Adhesive Transfer Tape 9380. This clear acrylic adhesive tape is designed to meet the demanding requirements of aerospace applications, providing durability, resilience, and high performance.

In the aerospace industry, where reliability, performance, and safety are paramount, having the right adhesive solution is crucial. 3M™ Adhesive Transfer Tape 9380 is specifically designed to address the unique challenges of aerospace applications. With its exceptional resistance to jet fuel, hydraulic fluid, solvents, humidity, moisture, and heat, it offers a versatile and dependable solution for various bonding needs.

Features and Benefits of 3M™ Adhesive Transfer Tape 9380

  • Excellent resistance to jet fuel and hydraulic fluid
  • Good solvent, humidity, and moisture resistance
  • High heat resistance
  • Clear acrylic adhesive tape
  • Ideal for aerospace applications
  • 5 mil thickness for reliable bonding

The Importance of Resistance to Jet Fuel and Hydraulic Fluid

Aerospace applications often involve exposure to harsh chemicals like jet fuel and hydraulic fluid. The 3M™ Adhesive Transfer Tape 9380 is specifically formulated to withstand these challenging environments. Its excellent resistance to jet fuel and hydraulic fluid ensures that the adhesive bond remains strong and reliable, even in the presence of these corrosive substances.

Solvent, Humidity, and Moisture Resistance for Enhanced Reliability

Apart from fuel and fluid resistance, 3M™ Adhesive Transfer Tape 9380 also offers good resistance to solvents, humidity, and moisture. These properties make it highly reliable in diverse aerospace conditions, preventing the degradation of the adhesive bond due to environmental factors. Whether it’s exposure to solvents or high humidity levels, this adhesive tape maintains its performance, providing long-lasting durability.

Heat Resistance for Challenging Environments

Aerospace applications often involve exposure to high temperatures. The heat resistance of 3M Adhesive Transfer Tape 9380 makes it suitable for such challenging environments. It can withstand short periods at temperatures up to 450°F (232°C) and longer periods up to 300°F (149°C). This characteristic ensures that the adhesive bond remains strong and intact, even in extreme temperature conditions.

Aerospace Industry Application

The aerospace industry demands adhesive solutions that can withstand the rigorous demands of aircraft construction, maintenance, and repair. 3M™ Adhesive Transfer Tape 9380 meets these demands with its superior performance. It is widely used in applications such as bonding interior panels, securing wire harnesses, attaching decorative trims, and many other aerospace bonding applications. Its versatility and reliability make it an ideal choice for various bonding needs in the aerospace industry.

How 3M™ Adhesive Transfer Tape Works

3M™ Adhesive Transfer Tape 9380 is a pressure-sensitive adhesive (PSA) provided on a special release liner. The tape is positioned adhesive-side down onto the surface where bonding is required, and then the liner is removed, exposing the backside of the adhesive to the joining surface. This allows for easy and precise application, ensuring a strong bond between the adhesive tape and the substrates.

The Strength and Resilience You Can Rely On

When it comes to aerospace applications, strength and resilience are crucial. 3M™ Adhesive Transfer Tape 9380 excels in both these aspects. It forms strong and tough bonds that can withstand the rigors of the aerospace industry. The tape’s durability ensures that the adhesive bond remains intact, even in challenging conditions such as vibrations, impacts, and fluctuations in temperature. With 3M™ Adhesive Transfer Tape 9380, you can have confidence in the longevity and performance of your bonded assemblies.

Technical Specifications and Typical Properties

  • Adhesive Type: Acrylic
  • Brand: 3M™
  • Total Tape Thickness without Liner (Imperial): 2 mil
  • Total Tape Thickness without Liner (Metric): 0.05 mm

For more detailed technical information, refer to the 3M™ Adhesive Transfer Tape 9380 Technical Data Sheet.

Environmental Performance and Compatibility

3M™ Adhesive Transfer Tape 9380 is designed to perform even in challenging environmental conditions. It exhibits excellent resistance to humidity and moisture, making it suitable for applications where exposure to moisture is a concern. The tape’s bond strength is not adversely affected by outdoor exposure, thanks to its resistance to ultraviolet (UV) radiation. Additionally, it offers good chemical resistance, holding securely even after exposure to various chemicals, including JP4 jet fuel and commonly used types of Skydrol® hydraulic fluid.

Technical Specifications and Typical Properties

Here are the technical specifications and typical properties of 3M™ Adhesive Transfer Tape 9380:

  • Adhesive Type: Acrylic
  • Brand: 3M™
  • Factory ISO Certification: No ISO Certification information available
  • Total Tape Thickness without Liner (Imperial): 2 mil
  • Total Tape Thickness without Liner (Metric): 0.05 mm

These specifications ensure that the tape meets the necessary standards for aerospace applications. The acrylic adhesive provides a reliable and strong bond, while the 2 mil thickness (0.05 mm) ensures optimal performance.

Please note that the absence of ISO Certification information does not imply a lack of quality or adherence to industry standards. 3M™ Adhesive Transfer Tape 9380 is designed and manufactured to meet the demanding requirements of aerospace applications.

3M Clear Transfer Tape TPM5: Perfect Solution for Sign-Making

3M Clear Transfer Tape TPM5: In the world of sign-making and graphic applications, adhesive transfer tapes play a vital role in achieving precise and efficient results. One such tape that stands out for its quality and performance is the 3M™ Clear Transfer Tape TPM5. This article will explore the features, applications, and benefits of the 3M™ Clear Transfer Tape TPM5, highlighting its significance in the sign-making industry.

1. Introduction

When it comes to creating signs, it is essential to have reliable tools and materials that ensure precision and durability. Adhesive transfer tapes, like the 3M™ Clear Transfer Tape TPM5, are specifically designed to meet the demands of sign-making applications. In this article, we will explore the features and benefits of this versatile tape, along with its various applications.

2. Overview of 3M™ Clear Transfer Tape TPM5

The 3M™ Clear Transfer Tape TPM5 is a high-quality adhesive tape that offers exceptional performance in sign-making and graphic applications. It is a clear transfer tape used for premasking or applying prespaced legends, particularly in situations where a clear transfer tape is desired. The TPM5 tape is solvent-free, making it a safe and reliable choice for sign-making projects.

3. Sign-making Accessories for 3M™ Reflective Sheeting

The 3M™ Clear Transfer Tape TPM5 is designed as a sign-making accessory for use with 3M™ Reflective Sheeting. It provides excellent adhesion and ensures optimal cutting, weeding, lifting, and transfer features. Whether you are working on commercial signs or traffic signs, the TPM5 tape complements the reflective sheeting and enhances the overall quality of the sign.

4. Applications and Benefits

4.1 Sign-making Applications

The 3M™ Clear Transfer Tape TPM5 finds wide-ranging applications in the sign-making industry. Some of the common applications include:

  • Traffic control signs: The TPM5 tape is ideal for applying graphics and legends on traffic signs. Its clarity and adhesive properties ensure a smooth and precise application.
  • Commercial signs: Whether it’s storefront signage or promotional displays, the TPM5 tape provides reliable adhesion and clarity, making it suitable for a variety of commercial sign applications.
  • Backgrounds, copy, and logos: The TPM5 tape is effective in applying backgrounds, copy, and logos on signs. Its solvent-free composition ensures compatibility with various sign materials.

4.2 Benefits of Using 3M™ Clear Transfer Tape TPM5

The use of 3M™ Clear Transfer Tape TPM5 offers several advantages for sign-making professionals:

  • Enhanced clarity: The clear transfer tape provides excellent transparency, allowing for accurate alignment and placement of graphics and legends.
  • Solvent-free formulation: The TPM5 tape is free from solvents, ensuring a safe working environment and minimizing potential health hazards.
  • Optimal cutting and weeding: The tape’s characteristics enable precise cutting and easy weeding, resulting in clean and professional-looking signs.
  • Reliable adhesion: The TPM5 tape offers strong adhesion to various surfaces, ensuring long-lasting and durable signage.
  • Compatibility with 3M™ ElectroCut™ Series 1170 Film: The Compatibility with 3M™ ElectroCut™ Series 1170 Film: The TPM5 tape is recommended for use with 3M™ ElectroCut™ Series 1170 Film, ensuring optimal performance and compatibility between the tape and the film.
  • Easy application: The tape’s transfer properties make it easy to apply graphics, legends, and other design elements onto signs without leaving residue or damaging the surface.
  • Versatility: The TPM5 tape is available in various widths, ranging from 6 inches to 48 inches, allowing for flexibility and adaptability to different sign sizes and designs.

5. Specifications

Here are the specifications of the 3M™ Clear Transfer Tape TPM5:

  • Adhesive Type: Rubber
  • Application: Commercial Signs, Traffic Signs
  • Brands: 3M™
  • Factory ISO Certification: No ISO Certification information available
  • Overall Length (Imperial): 100 yd
  • Overall Length (Metric): 91 m
  • Overall Width (Imperial): Varies depending on the item (ranging from 6 in to 48 in)
  • Overall Width (Metric): Varies depending on the item (ranging from 152.4 mm to 1,219.2 mm)
  • Total Tape Thickness without Liner (Imperial): 4 mil
  • Total Tape Thickness without Liner (Metric): 0.102 mm

References – 3M Clear Transfer Tape TPM5

3M Adhesive Transfer Tape 9379: The Ideal Aerospace Adhesive

3M Adhesive Transfer Tape 9379: Are you in search of an adhesive that offers exceptional resistance to jet fuel and hydraulic fluid? Look no further than 3M™ Adhesive Transfer Tape 9379. This transparent adhesive tape is designed specifically for the aerospace industry, providing reliable and durable bonds in even the harshest environments. With its excellent solvent, humidity, moisture, and heat resistance, this adhesive transfer tape is a go-to choice for aerospace applications. Let’s explore the features and benefits of 3M™ Adhesive Transfer Tape 9379 in detail.

The Need for Aerospace Adhesives

In the aerospace industry, where reliability and performance are paramount, choosing the right adhesive is crucial. Adhesives play a vital role in bonding various components and materials together, ensuring structural integrity and safety. When it comes to aerospace applications, the adhesive must possess exceptional resistance to jet fuel, hydraulic fluid, solvents, humidity, moisture, and heat. 3M™ Adhesive Transfer Tape 9379 checks all the boxes, making it the adhesive of choice for aerospace professionals.

The Superior Performance of 3M™ Adhesive Transfer Tape 9379

3M™ Adhesive Transfer Tape 9379 is a clear acrylic adhesive tape that offers excellent resistance to jet fuel and hydraulic fluid. Its unique formulation ensures the adhesive maintains its integrity even when exposed to harsh chemicals commonly found in the aerospace industry. Additionally, this adhesive transfer tape provides good resistance to solvents, humidity, moisture, and heat, making it a versatile and reliable choice for various aerospace applications.

Meeting Workplace Demands: Resilience and Reliability

When developing 3M™ Adhesive Transfer Tape 9379, 3M had the aerospace industry’s specific requirements in mind. The tape is engineered to withstand the rigorous demands of the industry, offering outstanding resistance to jet fuel, hydraulic fluid, solvents, humidity, moisture, and heat. Whether it’s bonding structural components or securing vital systems, this adhesive transfer tape provides the resilience and reliability necessary for aerospace applications.

Product Description: A Closer Look at 3M™ Adhesive Transfer Tape 9379

3M™ Adhesive Transfer Tape 9379 is made with a modified acrylic adhesive known for its exceptional performance in the presence of harsh chemicals like jet fuel and hydraulic fluid. The tape is coated onto a clear polyester removable liner, ensuring easy application and removal. It is available in a rolled tape format with varying widths, providing flexibility and convenience for different bonding needs.

Typical Properties: Understanding the Key Characteristics

  • Adhesive Type: Acrylic
  • Brand: 3M™
  • Factory ISO Certification: No ISO Certification information available
  • Total Tape Thickness without Liner (Imperial): 2 mil
  • Total Tape Thickness without Liner (Metric): 0.05 mm

Environmental Performance: Withstanding Harsh Conditions

3M™ Adhesive Transfer Tape 9379 excels in various environmental conditions, proving its reliability and durability. Let’s explore its key performance attributes:

Bond Build-up: The bond strength of 3M™ 9379 adhesive increases over time and temperature, ensuring a strong and long-lasting bond.

Humidity Resistance: High humidity has minimal effect on the adhesive’s performance. After exposure for 7 days at 90°F (32°C) and 90% relative humidity, bond strengths remain high.

U.V. Resistance: When properly applied, the adhesive bond between impervious parts is not adversely affected by outdoor exposure, providing UV resistance.

Temperature Cycling Resistance: The bond strength of 3M™ 9379 adhesive generally increases after cycling four times through different temperature extremes, ensuring stability and reliability. These cycles include 4 hours at 158°F (70°C), followed by 4 hours at -20°F (-29°C), and finally 16 hours at 72°F (23°C).

Chemical Resistance: The adhesive bond formed by 3M™ 9379 adhesive remains secure even after exposure to various chemicals, including JP4 jet fuel and commonly used types of Skydrol® hydraulic fluid.

Heat Resistance: With a temperature range of up to 450°F (232°C) for short periods and up to 300°F (149°C) for longer durations, the 3M™ 9379 adhesive maintains its performance in high-temperature environments.

Low Temperature Service: The adhesive is also suitable for low-temperature applications, with a service range down to -40°F (-40°C). However, it’s essential to evaluate bonded substrates for continuous exposure to low temperatures.

Extended Liner 920XL: 3M Adhesive Transfer Tape

Extended Liner 920XL: 3M™ Adhesive Transfer Tape Extended Liner 920XL is a translucent adhesive tape that offers reliable bonding capabilities for a wide range of materials. With its pressure-sensitive adhesive and user-friendly features, this tape is a valuable tool in many industries. Let’s explore the key details and benefits of the 3M™ Adhesive Transfer Tape Extended Liner 920XL.

Introduction

3M™ Adhesive Transfer Tape Extended Liner 920XL is a general purpose tape with a pressure sensitive adhesive mounted on a removable extended paper liner for easy liner starting and removal. It is ideal for a variety of applications, including cardboard shipping boxes, overnight mailer envelopes, pharmaceutical outserts, point of purchase displays and advertising, core starting, business forms, and paper-to-paper applications.

The tape has a high initial adhesion and good shear holding power, making it ideal for bonding a variety of different materials. It is also resistant to temperature extremes, making it suitable for use in a variety of environments.

Features

  • Pressure sensitive adhesive ideal for bonding a variety of materials
  • Removable extended paper liner for easy liner starting and removal
  • Tack free tape roll edges for ease of use and reduced equipment maintenance
  • Dry edge and finger lift edge liners for added user convenience
  • A variety of adhesives and liner materials available to meet application requirements
  • This product features a thinner liner than 450XL

Applications

  • Cardboard shipping boxes
  • Overnight mailer envelopes
  • Pharmaceutical outserts
  • Point of purchase displays and advertising
  • Core starting
  • Business forms
  • Paper-to-paper applications

Specifications

  • Adhesive Type: Acrylic
  • Brand: 3M™
  • Industries: General Industrial, Packaging, Print, Medical, Paper, Retail
  • Maximum Operating Temperature (Fahrenheit): 180 ℉
  • Minimum Operating Temperature (Fahrenheit): -40 ℉
  • Overall Length (Imperial): 1,000 yd
  • Overall Length (Metric): 914 m
  • Overall Width (Imperial): 0.5 in
  • Overall Width (Metric): 12.7 mm
  • Primary Liner: 42.5# Densified Kraft Paper
  • Primary Liner Color: White
  • Primary Liner Thickness (Imperial): 2.5 mil
  • Primary Liner Thickness (Metric): 0.06 mm
  • Total Tape Thickness without Liner (Imperial): 1 mil
  • Total Tape Thickness without Liner (Metric): 0.025 mm
  • Units per Case: 12.0 Roll

Order Information

3M™ Adhesive Transfer Tape Extended Liner 920XL is available for purchase online or at your local 3M dealer. To place an order, please visit the 3M website or contact your local 3M dealer.

Contact Information

For more information about 3M™ Adhesive Transfer Tape Extended Liner 920XL, please visit the 3M website or contact your local 3M dealer.

3M™ Adhesive Transfer Tape Extended Liner 920XL: A Reliable Solution for Your Adhesion Needs

3M™ Adhesive Transfer Tape Extended Liner 920XL is a reliable solution for your adhesion needs. It is ideal for a variety of applications and is made with high-quality materials that are designed to last. With its easy-to-use design and long-lasting performance, 3M™ Adhesive Transfer Tape Extended Liner 920XL is the perfect choice for your next project.

Pressure Sensitive Adhesives for Versatile Bonding

The 3M™ Adhesive Transfer Tape Extended Liner 920XL is designed with pressure-sensitive adhesives that make it ideal for bonding a variety of different materials. Whether you need to join cardboard, paper, films, plastics, foams, or metals, this tape provides a strong and durable bond.

Convenient Dry Edge and Finger Lift Edge Liners

To enhance user convenience, the 3M™ Adhesive Transfer Tape Extended Liner 920XL features dry edge and finger lift edge liners. These liners extend beyond the width of the adhesive, making it easy to start and remove the liner. The dry edge and finger lift edge on each side of the tape facilitate quick and effortless liner removal.

Tack Free Tape Roll Edges for Ease of Use

The tape roll edges of the 3M™ Adhesive Transfer Tape Extended Liner 920XL are tack free, offering ease of use and reducing equipment maintenance. With tack-free edges, you can handle the tape without any sticky residue interfering with the application process. This feature ensures efficient and hassle-free usage.

Easy Liner Starting and Removal for Smooth Workflow

The easy liner starting and removal capability of the 3M™ Adhesive Transfer Tape Extended Liner 920XL helps keep jobs running smoothly. The extended liners allow for easy starting and removal, saving time and minimizing interruptions in your workflow. This feature contributes to enhanced productivity and efficiency.

A Variety of Adhesives and Liner Materials

The 3M™ Adhesive Transfer Tape Extended Liner portfolio offers a range of adhesive options to meet diverse application requirements. The tape utilizes 3M™ Adhesive 400 Acrylic, which exhibits high initial adhesion and good shear holding power. It is especially well-suited for adhesion to paper materials. The availability of different release liner materials, including densified kraft, extensible kraft, and kraft glassine, ensures compatibility with various surfaces and substrates.

Understanding Adhesive Transfer Tapes

3M adhesive transfer tapes, including the 3M™ Adhesive Transfer Tape Extended Liner 920XL, consist of rolls of pressure-sensitive adhesive pre-applied to a special release liner. These tapes are designed without any backing material, featuring adhesive on one side and a liner on the other. During application, the tape is positioned adhesive side down onto the surface, and the liner is removed, exposing the adhesive for bonding.

Bringing Innovation through Science and Expertise

3M is a leader in adhesive technology, driven by a commitment to scientific advancements and innovation. In their Industrial Adhesives and Tapes Division, they apply the science of adhesion to deliver innovative solutions that improve design and manufacturing processes worldwide. By leveraging their expertise, 3M helps customers deliver competitive products to the market more efficiently.

Sources

  1. www.3m.com/3M/en_US/p/d/v000090092/
  2. www.3m.com/3M/en_US/p/d/v000090054/
