Philips Greenspace Flex 911401720822

RS378B MR16 D78 R-R AJ D
Philips Greenspace Flex 911401720822

Greenspace Flex

RS378B MR16 D78 R-R AJ D

– ° – – – Electronic transformer – Gray

It delivers super flexibility, complete product range and seamlessly system integration to Hospitality customers.

Product data
General Information     Light source engine type LED
Beam angle of light source – °
Light source color   Operating and Electrical
Number of gear units 1 unit   Input Voltage 220 to 240 V
Driver/power unit/transformer Electronic transformer   Input Frequency 50 to 60 Hz
Driver included No   Power Factor (Min)
Optic type
Optical cover/lens type   Controls and Dimming
Luminaire light beam spread   Dimmable No
Control interface
Connection External connector   Mechanical and Housing
Cable   Housing Material Aluminum
Protection class IEC   Reflector material
Glow-wire test Temperature 600 °C, duration 30 s   Optic material Polymethyl methacrylate
Flammability mark   Optical cover/lens material
CE mark   Fixation material Aluminum
ENEC mark   Optical cover/lens finish
Warranty period 3 years   Overall length 0 mm
Constant light output No   Overall width 0 mm
Number of products on MCB of 16 A type B   Overall height 104 mm
EU RoHS compliant Yes   Overall diameter 85 mm

Greenspace Flex

Color Gray   Maximum dim level Not applicable
      Suitable for random switching No
Approval and Application
Ingress protection code IP20 [ Finger-protected]   Product Data
Mech. impact protection code IK04 [ 0.5 J standard plus]   Full product code 911401720822
      Order product name RS378B MR16 D78 R-R AJ D
Initial Performance (IEC Compliant)     Order code 911401720822
Luminous flux tolerance +/-10%   Numerator – Quantity Per Pack 1
Init. Corr. Color Temperature – K   Numerator – Packs per outer box 48
Init. Color Rendering Index   Material Nr. (12NC) 911401720822
Power consumption tolerance +/-10%   Net Weight (Piece) 0.020 kg
Over Time Performance (IEC Compliant)
Median useful life L80B50 50000 h
Application Conditions
Ambient temperature range -20 to +45 °C
    Dimensional drawing

Cut out: Ø102
